KM-3600
เครื่องตัดท่อร้อยสายไฟ (ท่อค็อท)
KM-3600 Corrugated Hose Cutting Machine
DIGITAL CUTTING MACHINE
- - Digital Window for easy set-up
- - Push button set-up for all machine functions
- - Count of pieces needed
- - Five-memory storage
- - Various warning messages and alarm functions
- Various Sensors
- - Material run-out sensor
- - Default Value sensor for blade height
- - Proximity sensor
- - Power sensor to save working data in case of power failure
- Feeding Part
- - Material Hanger and Guide
- - Aux. Roller and Feeding roller
- - A knob for roller lift-up
- - Roller friction adjusting nut
- - Material pressing plate and adjusting nut
- Cutting Part
- - Upper/Lower/Wing blades
- - Carbonated Blade life two times the life of competitor model
- - Operate friendly design for easy replacement
| Dimensions(W x D x H) | 435 x 480 x 380 |
| Weight(kg) | 38 |
| Cutting Material | Corrugated Hose(Up to 40pie) |
| Max. cutting width | 100mm |
| Power supply | 110/220 VAC, 50/60Hz, Single Phase |
| Power consumption(WAT) | 22 W ~ 150 W |
